Features:
1. The main functions of GTK Series Thermostatic Water Mixing Valves are avoiding scaling, protecting safety, and constant temperature control
2. The application heat source is from small geothermal air conditioning and solar energy. These heat sources have high temperatures and cannot be applied directly to domestic hot water. Through the water mixing valve, the high-temperature hot water can be converted into directly applicable hot water (constant temperature range: 35~60°C;), which provides a safety function compared to the hot water system of modern living environment.
3. It is suitable for the control valve with constant temperature protection and setting before bath faucet. It has the function of a one-time setting and permanent application.
4. It is suitable for household hot water appliances equipped or underfloor heating to meet the requirements of constant temperature range and flow.
5. No matter how the temperature and water pressure change, it can ensure stable water extraction.
Parameter:
【Valve Body Material】 Brass 57-3
【Diameter of Valve】DN20
【Type of Threads】 External Teeth
【Maximum Working Pressure】 10 kgf /c㎡
【Kvs】1.9 m³/h
【Temperature Control Range】35~60°C
【Spring Material】 Stainless Steel
【Threaded Connection】G Standard Thread
【Note】 The product comes with the lid
Advantages:
Economic advantages, good quality;
Easy and convenient installation, automatic constant temperature after one adjustment; Prevent burns and cold shocks and avoid the feeling of sudden cold and heat
Application:
- Kitchen sink, bathroom sink, isothermal water outlet, faucet in front;
- the bathroom and the public outlet for hot springs in front;
- The socket of the solar system is at the front
