Specifications:
- Mounting Type: Base installation
- Coil voltage: 9-36VDC
- Contact shape: SPST-NO (DM) (1 Form X)
- Switching voltage: 900VDC-max
- Features: Economizer, sealed-airtight
- Termination style: column head, wire lead
- Working temperature: -40°C to 85°C
- Must pull in voltage: 9 VDC
- Must release voltage: 6 VDC
- Contact material:-
- Coil power:-
- Coil resistance:-
- Rated contact (current): 500 A
- Working time: 15ms
- Release time: 12ms
- Coil current: 130mA
Package Included:
- 1 x Set of Contactor Relay
